Product Description
UCFL212 2-Bolt Flange Cast Iron Unit
Key Features
UCFL212 2-Bolt Flange Bearing has a wide inner ring with two set screws that are for attachments to the shaft. This UCFL212 2-Bolt Flange Bearing has a combination of a chrome steel set screw insert bearing and an oval cast iron 2-Bolt Flange housing. The UCFL200 Series are equipped with insert ball bearing which has two grub screws to allow tightening against the shaft once fitted in place. Our mounted blocks are pre-lubricated with grease ensuring they are ready for use upon arrival.
Applications / Industries
UCFL212 2-Bolt Flange Cast Iron Bearings are widely used in various applications such as HVAC Systems, Manufacturing Equipment, Conveyor Systems, Film Processing Machinery, Fan Assemblies, Farm Machinery, Feed Mills, among other Industrial Applications.
Product Videos
Custom Field
Inner Diameter 60mm
Overall Length 250mm
Overall Height 140mm
Bolt Hole to Bolt Hole 202mm
Housing Material Cast Iron
Insert Material Chrome Steel SAE-52100
Lubrication Chevron SRI-2 Grease
Static Load 7,515 lbf
Dynamic Load 10,718 lbf
Speed Limit 2,800 RPM
Country of Origin China
Interchange Numbers PCJT60-N-FA125, KFC2-25-60, KFC2-45-60, UCFL212E, SFT-60EC, SFT-60A, VFT-60E, UCFT212-60, VF2S-212, 124171-F2B-SC-60, YCJT-60, FX3-U212N, FHSFT212G, SFT-60, SFT-212, FYT-60-TM, UCFL212-60MM, FX3-U2M60N
